"Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Thu 20 Jun 2013, 2:09 pm

It's been a while since Kit one arrived and there have been a few since so thought it was about time to post some images of the progress so far so here goes.

Chassis



Front axle and Spring Attached to Chassis



Rear Springs + boxes



Front Hub



Rear Axle



That's the progress so far hopefully sort the rear hubs and trims out this weekend so we can drop it onto the wheels.


Cheers
Nick & Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  lynnr on Thu 20 Jun 2013, 2:16 pm

Hi Nick and Ken

Great to see another build in progress.

lynnr

Number of posts : 2717
Age : 48
Location : Highland, 4inch showman
Registration date : 2010-08-06

View user profile http://www.pbase.com/uisge

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  SSGR on Fri 21 Jun 2013, 8:39 am

Looking good Nick and Ken. Nice to see another SWB build.

John

SSGR

Number of posts : 87
Age : 51
Location : North Essex
Registration date : 2012-05-14

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Wed 26 Jun 2013, 12:11 pm

We have now completed all the kits delivered to date so have uploaded some more images, the only bits not fitted are the rear wheel centres as these are going to match the body colour and we have not brought the paint yet, also the rear inside tyres are missing valve caps as these hit the spring boxes when fitted so will be taking the wheels back off later to fit shorter valves to the inside rims on the rear.







Thanks for looking

Cheers
Nick and Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  Robfishman on Wed 26 Jun 2013, 2:57 pm

Well done chaps, it's looking good. Keep the posts coming.

Robfishman

Number of posts : 947
Age : 42
Location : Chandlers Ford Hampshire 4inch showman
Registration date : 2010-11-26

View user profile http://www.robertfish.net

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  Hecter on Mon 01 Jul 2013, 1:32 pm

Looks lovely in the red, what method did you use for smoothing down the steering wheel and getting rid of excess solder?

Hecter

Number of posts : 50
Age : 22
Location : Luton
Registration date : 2013-02-13

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Mon 01 Jul 2013, 2:25 pm

Hi Hecter,
We did not do anything I just chucked it in the blasting cabinet as the brazing is soft in cleaned up pretty well without much effort.

Cheers
Nick

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  Hecter on Wed 03 Jul 2013, 1:22 pm

Ah ok, we have a little bit of splatter on ours as well. although i think mark may have had a go at cleaning it up, have to wait and see

Hecter

Number of posts : 50
Age : 22
Location : Luton
Registration date : 2013-02-13

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  hartshaulage on Fri 14 Feb 2014, 12:55 pm

hi Foden SWB, Ive been following your progress for a while before i joined the site and signed up for my own Foden SWB, Just wondering how the progress is goign haven't seen an update for a while

hartshaulage

Number of posts : 223
Age : 27
Location : Ilkeston, Derbyshire
Registration date : 2014-01-22

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Sat 15 Feb 2014, 1:18 am

Hi,
We have completed the smoke box and chimney, but have not started on the cylinder and valve gear yet as my father has been ill since October, he is getting better now but we have just gutted the kitchen and dinning room so wont get a chance to look at the steam engine for a bit.  I have posted some update photo's for the smoke box below we have also finished and fitted the water tank but the weather has not been conducive with rolling it outside for a photo.

Cheers
Nick and Ken




FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Chuttie 4.5 in Foden Build

Post  Old Down Trevor on Tue 18 Feb 2014, 10:42 am

Hello Nick and Ken- it seems to be coming along nicely. I took delivery of 11 kits on 14th Jan and am busy working on chassis etc.

I liked the finish of the smoke box and chimney- can you tell me what paint you used. It looks a little like the heat resistant paint sold for wood burner stoves.

Regards

Old Down Trevor

Old Down Trevor

Number of posts : 13
Location : Bristol
Registration date : 2014-01-09

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Tue 18 Feb 2014, 11:22 am

It's Satin black high temp engine paint from Halfords I thinned it and sprayed it from my spray gun.

Cheers
Nick

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Mon 22 Dec 2014, 5:40 am

Just a few photo's of the current progress need to finish build the gear change and fitting the guards to check fits before disassembly to paint the various bits.

" />
" />
" />
" />

Have a good Christmas

Nick + Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  hartshaulage on Wed 24 Dec 2014, 11:27 am

Hi Ken & Nick

Merry Christmas

Your Foden is looking amazing so nice to see the progress, i cannot wait until mine looks like this, hopefully next year

Keep up the good work

Russ

hartshaulage

Number of posts : 223
Age : 27
Location : Ilkeston, Derbyshire
Registration date : 2014-01-22

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  phil gomez on Wed 24 Dec 2014, 11:39 am

Hi Ken & Nick.
Your wagon is looking brilliant, I agree with Russ. I to cannot wait to get to your stage of the build - one day?
Merry Christmas to you all.

Phil.

phil gomez

Number of posts : 150
Location : pagham, west sussex
Registration date : 2014-03-15

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Sun 11 Jan 2015, 4:32 am

Well with the Christmas break we made a lot of progress and are actually up to date with the kits we have which has not been the case for a while, so a few photo's to document the progress.



After some fettling and modification we have a fire door that stays open, reduced the spacer bushes, changed the top bolt to M4 and tapped the baffle plate and then ground the bolt flush and hey presto the door actually locks open.







Cheers

Nick and Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  SSGR on Mon 12 Jan 2015, 5:10 am

Looking good Nick and Ken. I need to play catch up!

John

SSGR

Number of posts : 87
Age : 51
Location : North Essex
Registration date : 2012-05-14

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  atomenter on Mon 12 Jan 2015, 11:20 am

Hi Guys
Great pictures, looks good, brings back memories of just a couple of years ago with my build.  I think the gear and chain guards look especially good, I did mine black but your choice looks better.  The rear wheels look similar - see below



All the beat with the build and keep the pics coming

Tom

atomenter

Number of posts : 163
Location : FIFE
Registration date : 2008-06-26

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Mon 12 Jan 2015, 11:30 am

The rear wheels do look similar we are currently debating painting the wheel rim yellow like yours or painting it red then running a yellow stripe inside of the holes on the cover plates to look similar to the fly wheel. The centre hubs on ours are the colour that we intend to use on the body panels so it should be vivid Shocked

Cheers
Nick


FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  hartshaulage on Mon 12 Jan 2015, 1:24 pm

Hi Nick & Ken

Your Foden i looking amazing, a yellow lorry will make a change from the normal colour scheme's out there, Shouldn't imagine it will be long until you can run the engine on air

Keep up the good work

Russ

hartshaulage

Number of posts : 223
Age : 27
Location : Ilkeston, Derbyshire
Registration date : 2014-01-22

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Wed 14 Jan 2015, 11:15 am

Had a bit more of a fiddle and have now done a bit of cosmetic work on the covers.







Cheers
Nick

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  He Who Must Not Be Blamed on Wed 14 Jan 2015, 12:08 pm

Very nice indeed. [insert raised thumb icon here]

Just out of interest: what's the upright brass cylinder thinghy on top of the elbow, on the side?

He Who Must Not Be Blamed

Number of posts : 28
Location : Europe
Registration date : 2013-08-02

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Wed 14 Jan 2015, 12:12 pm

It's the oiler for the second shaft gears.

Cheers
Nick and Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  FodenSWB on Sun 18 Jan 2015, 8:40 am

As it was sunny and we have now lined the wheels I thought I would snap another couple of photos outside to show the whole engine so far with the pinstripes, as you can never have too many photos in my opinion Very Happy





Just need another kit now as it is strange not having anything to do at the moment.

Cheers
Nick & Ken

FodenSWB

Number of posts : 27
Location : Tewkesbury
Registration date : 2012-08-31

View user profile

Back to top Go down

Re: "Chuttie" - 4.5" Foden Build Progress

Post  phil gomez on Sun 18 Jan 2015, 10:28 am

Hi Nick and Ken.
I must say have nice your engines looking it gives me something to look forward too.
Must be getting a bit heavy now I.e. Pushing it around (keeps you fit I would imagine).
Thanks for the pictures.
Phil.

phil gomez

Number of posts : 150
Location : pagham, west sussex
Registration date : 2014-03-15

View user profile

Back to top Go down
